3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase

  • 1
  • 2
  • 3

Brand Name : SKYWIN

Model Number : SK-380S

Certification : CE

Place of Origin : Guangdong, China

MOQ : 1 set

Price : 6,000 USD

Payment Terms : L/C, T/T

Type : Multi-Function Packaging Machine

Packaging Type : Bags, Belt, Pouch

Applicable Industries : Hotels, Food & Beverage Factor

Condition : New

Automatic Grade : Automatic

Warranty : 1 Year

Marketing Type : Ordinary Product

Core Components : Motor, PLC, Gear, Bearing

Material : 304 Stainless Steel Material

Phase : Single

Control system : PLC control

Packaging Material : plastic, Paper,

Function : FILLING, Wrapping, Sealing

Application : Food

Machine weight : 650KG

Packing speed : 250-300bags/min

Usage : A date printer

Contact Now

3 Servo Automatic Controlled Flow Pillow Snack Biscuit Sugar Packing Machine

3 Servo Motors; Painted steel cover; Schneider Switches; PLC control system; High Speed Flow Packing Machine; conveyor length 2.4m

3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase



Product Details

SK-380S

flow pack packaging machine


  • 3 SERVOS---1.FILM&END SEALER/2.CENTER SEALER/3.CONVEYOER
  • One ink type date printer
  • Standard conveyor belt length 2540mm, side plate support.
  • Photo sensor
  • With Middle plastic brush or stainless steel belt.
  • Packing speed: 250-300bag/min (Subject to material and thickness of film and packaging type)
  • Bag size:Length 80-500mm, Width 60-150mm, Height 5-45mm
  • Max outer diameter < 300 mm
  • Max width of the packing film: 380mm
  • Max width of the packing film: 380mm
  • Packing film thickness: 0.03-0.07mm
  • Total power consumption: 5.6KW / Single 220VAC/50Hz
  • Machine Size: 4200 x 950 x 1650mm (L x W x H)
  • Food contact part 304 Stainless Steel
  • Machine weight: 650 kg



SK-530S

flow pack packaging machine


  •   304 Stainless steel cover&Structure.
  •  3 Delta Servo Motors
  •  Schneider Switches
  •  PLC control system
  •  Upper and Down Knife Jaw Temperature separate control
  •  Feeding roller without temperature control
  •  Heating rollers&Heating plate with temperature control
  •  Sealing rollers single temperature control.
  •  Film width 370mm
  •  included Ink date printer
  •  Speed: 30 to 350 packs/minute
  •  Bag size:
  •  Length 80-500mm(Adjustable by screen), Width 35-160mm, Height 5-55mm
  •  Max outer diameter < 300 mm,
  •  Max width of the packing film: 380mm,
  •  Packing film thickness: 0.04-0.07mm
  •  Machine dimension: (L x W x H): 4000 x 950mm x 1650mm
  •  Power consumption: Single phase: 220V/50Hz
  •  Total Power 6kw
  •  Heating power 3.5kw
  •  End seal servo 1kw,film servo 0.75kw,Conveyor servo 0.4kw
  •  Gross weight: 450kg
  • Packing materials:OPP/PE/PVC/CPP/PTPE/KOP/CPP/ALUMINUM FILM.Conveyor feeding belt for the Flow packing machine





3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase

3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase

3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase

3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase



Packing Sample

3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase



3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase



More details, Please contect with us!!!





3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase



Packing&Shipping

3 Servo Automatic Controlled Flow Pillow Biscuit Sugar Packing Machine Single Phase



Welcome to contect me!
